- Case Study -

Effective
Quality management with BCT Inspector

Continuous linking of drawing data from design to the shopfloor at Siemens Mobility GmbH

mo-keyvisual-allach-preview

Integrated BCT solutions in Siemens NX, Teamcenter and Opcenter Quality reduce the complexity of inspection planning

In order to optimize the inspection planning for Siemens Mobility GmbH, a linking of the inspection data with the design data was made possible



Challenges

Many different software solutions and programs complicate the inspection process for Siemens Mobility GmbH.

  • High manual effort for a detailed inspection on the part of the inspector and worker
  • Entering the characteristics in Siemens Opcenter Quality (formely QMS Professional) takes additional time and is prone to errors
  • Linking the design data with the inspection data
  • Reduce complexity in inspection planning



The key to success

  • Inspection planning with Siemens Opcenter Quality management software requires characteristic data from 3D model
  • BCT Inspector transfers this data directly to Siemens Opcenter Quality for effective quality management
  • BCT Inspector enables characteristic identification and ballooning of geometry and part
  • Over the entire life cycle of the part, its inspection characteristics are kept
  • Critical characteristics can be taken over into the inspection planning process and are sent to Siemens Opcenter Quality
  • During a revision of the geometry data, the BCT Inspector automatically recognises the changes of the ballooned characteristics

the results in a quick view

  • Process stability and continuous process documentation
  • Automatic update of the feature list in case of design changes (incl. backtracking)
  • The integrated software solution reduces the complexity for the worker with the help of feature- and work-specific guidance through the inspection process
  • Continuous linking of drawing data from design to the shopfloor

usecase_siemens_mobility





Siemens Mobility GmbH



Effective
Quality management with BCT Inspector

Case Study
